Fanuc Alpha 1iA-S/AWF Wire EDM
Stock Number: 0484
Fanuc Alpha 1iA-S/AWF
Age: 1999
Condition: As Is, Where Is
The FANUC wire cut electrical discharge machine - Alpha 1iA-S/AWF Compact has been developed as a result of the past 28 years of FANUC CNC controls, electronics and wire EDM experience. The Alpha 1iA-S/AWF is a "Next Generation" model that responds to our customer's need for high performance, high reliability, and low cost operation. This machine includes not just one, but four (4) separate Micro-Processors: numerical control (64 bit), digital power supply (32 bit), graphics functions (32 bit), and digital servo system (32 bit). The World's Fastest Cutting AC Power Supply.
Click to view larger photo
| Specification | Description |
|---|
| Machining Stroke ( X x Y x Z) | 21.22" x 14.56" x 7.34" |
| UV Axis Travels | +/- 2.364" |
| Taper Capacity | +/- 30 Deg. at 3.26" |
| Maximum Workpiece Size | 33" x 27.3" x 7.34" |
| Maximum Workpiece Weight | 2,200 LBS |
| Rapid Traverse | 35.4 ipm |
| Wire Guide System | Round Diamond Die Guide |
| Resolution | .00004" |
| Wire Diameter Capability | .004" - .012" |
| Wire Tension | 250-2500g |
| Wire Feed | 0-590 ipm |
| Maximum Wire Spool | 22LBS |
| Total Volume of Dielectric | 329 Gallons |
| Input Power | 200-220V, 3-Phase, 13 KVA |
| Approx. Machine Footprint Dimensions | 128" X 103" X 91" |
| Approx. Machine Weight | 7,700 Lbs |
Equipped With:
- Fanuc High Speed Digital / AC Power Supply
- Fanuc Series 18iW 64 bit CNC Control
- Heidenhain Linear Glass Scales - X and Y Axis Only
- 30 Degree Taper Cutting Capability
- Fanuc Serial / Digital AC Servo Motors
- Five Controllable Axis (X,Y,U,V, Z)
- Resolution of .000004"
- Absolute Position Detection System
- Column Mounted Independent U and V Axis Slides
- Automatic Wire Feed System (21 sec. Spark to Spark)
- Anti-Crash Protection
- CNC Operator Panel - Swing Mounted/Adjustable
- 10.4" Color LCD
- Programmable "Z" Axis
- AI function - Automatic Setting of Cutting Conditions
- Handy Controller (Hand Held Pendant)
- Quick Conversational Programming
- Automatic Water Level Control in Work Tank
- Operator Guidance Screens for Operation, Alarms, and Maintenance
- RS232C Input/Output Port for Reader/Punch
- Part Program Storage Capacity - 3280 Feet
- Automatic Power Recovery
- Automatic Restart
- Wire Center Path Calculation G41/42
- Coordinating System Rotation
- Reverse Copy (Symmetry) M96/97
- Automatic Corner Rounding
- Low Air Pressure Alarm
- Retrace
- Dielectric Water Filtration Unit
- Wire Breakage Locations Display
- AWF Hole Search Function
- Electric Chiller
- All Available Manuals and Accessories
